Wiper Arm Connector Types: J-Hook, Push Button, Pinch Tab

Buy links on this page go through our /go/ redirects to the manufacturer or retailer. We earn nothing from them today; that may change. Disclosure.

Quick answer

Wiper blades don't fail to fit because the inch length is wrong — they fail because the metal arm on the car doesn't match the plastic adapter in the box. Rain-X, Bosch, and TRICO group front wiper arms into six main styles: J-hook (U-hook), push button (top lock), pinch tab, side pin / side lock, bayonet, and newer integrated-spray arms. Lift the arm an inch off the glass (with a towel underneath) and match its end to the chart below.

Check arm style by vehicle: these maker lookup tools show both the inch length and the exact adapter step for your car.

Bosch ICON Rain-X Blade Size Finder TRICO Size & Install Finder

The 6 common front wiper arm connectors

The four most common front wiper arm families and the corresponding adapter numbers in the 2025 Bosch Wiper Blade Catalog.

Arm type	What the metal arm looks like	How it releases	Adapter notes from Bosch, Rain-X & TRICO
J-Hook / U-Hook 9×3 mm & 9×4 mm	Curved metal hook shaped like the letter J or U at the tip of the arm.	Press or flip the small lock tab inside the hook curve and slide the blade down toward the base of the arm.	The most common arm on older domestic and many Asian vehicles. Most aftermarket blades ship with the 9×3 / 9×4 hook adapter already pre-installed in the center bracket.
Push Button (PTB) 19 mm & 22 mm	Straight hollow rectangular sleeve at the end of the arm with a square hole on top.	Press the square button on top with a thumb or flat screwdriver tip and slide the blade straight out of the sleeve.	Common on Volkswagen, Audi, Ford, Volvo, and BMW. Come in two widths: standard 19 mm and narrow 16 mm or wide 22 mm. In Bosch ICON, push-button arms require an OE suffix blade.
Pinch Tab 15 mm & wide pinch tab	Open channel at the end of the arm with two side ears or tabs that clip over the blade bracket.	Pinch the two side tabs together (or pinch and lift the top cap) and slide or tilt the blade forward out of the channel.	Used across many GM, Chrysler/Jeep, Mercedes-Benz, BMW, and Hyundai/Kia models. Requires a multi-adapter (such as Bosch ICON OE's #2/#4 adapter).
Side Pin / Side Lock 17 mm & 22 mm pin, or offset claw	Straight arm with a round steel pin sticking out horizontally from the side, plus an L-shaped guide tab.	Rotate the blade slightly to clear the L-tab (or press the side lock tab) and slide the blade sideways off the steel pin.	Found on several BMW 3/5-Series, Mercedes-Benz, Volvo, and Ford models.
Bayonet	Flat, straight metal blade tang with a small round nub or hole near the tip.	Depress the small round button where the tang enters the blade and pull the blade straight off the end of the arm.	Older Renault/European arms and heavy-duty applications.
Integrated Spray / Proprietary Locks Slide-lock, Mercedes AquaBlade, Volvo/Tesla jet	Fluid nozzles and hoses are built directly into the wiper blade or proprietary sliding cap.	Release the slide lock and disconnect the washer fluid quick-coupler if the spray bar is part of the blade.	Multi-clip universal blades will not replace heated or integrated-jet blades; Bosch makes vehicle-specific Aerotwin and Envisage sets for these arms.

Why the 19 mm vs 22 mm push-button distinction matters

On Volkswagen, Audi, and Ford forums, the single most common frustration is buying a blade that says "fits push-button arms" only to find the plastic adapter is 3 mm too narrow or too wide for the metal sleeve. Rain-X's installation guide and Bosch's 2025 Wiper Catalog both separate 19 mm push button from 22 mm push button (and narrow 16 mm on select newer European cars). If the adapter has side play inside the metal sleeve, it is the 19 mm clip sitting inside a 22 mm arm — swap to the wider adapter included in the multi-clip pack before driving.

Does my car need a "Service Position" before I lift the arms?

On many modern cars (including Volkswagen, Audi, BMW, Volvo, Subaru, and Ford models), the wiper arms park deep under the rear edge of the hood. If you try to pull the arm straight up while the car is parked normally, the metal arm will hit the painted hood edge and chip the paint. Check your owner's manual for Wiper Service Position (often triggered by turning the ignition off and holding the wiper stalk down once, or via the center screen under Vehicle → Service) so the arms sweep up vertically onto the glass and stop there.

Never leave a bare arm standing up: once the old blade is off, lay the arm back down onto a folded microfiber towel on the windshield while you snap the right adapter onto the new blade. A bumped bare arm snaps down hard enough to crack laminated glass.

How we work: connector names and dimensions on this page come from Bosch's 2025 Windshield Wiper Catalog, Rain-X's installation instructions, and TRICO's installation guides. Sources are listed below.

Questions people ask

What is the most common wiper arm connector?

The 9x3 mm (and 9x4 mm) J-hook arm is the traditional standard on older domestic and many Asian vehicles, and most aftermarket wiper blades ship with the J-hook adapter pre-installed. Many newer European and domestic cars use push-button (top-lock), pinch-tab, or side-pin arms instead.

What is the difference between 19 mm and 22 mm push-button wiper arms?

Both use a hollow rectangular sleeve at the end of the arm with a square release button on top, but the metal sleeve is either 19 mm or 22 mm wide (with a 16 mm narrow version on select cars). A 19 mm adapter will wobble inside a 22 mm arm, so use the matching width clip from your blade's multi-adapter pack.

Why won't my wiper arms lift up off the windshield?

Many modern vehicles park the wipers below the hood line. Pulling them up from the parked position can chip the hood paint. Use your car's Wiper Service Position (check the owner's manual — often triggered with the wiper stalk right after turning off the ignition) to park the arms upright on the glass first.

Sources

Last checked Oct 23, 2026. Wiper part numbers and arm adapters change by trim and build year; confirm with the maker's part finder or your owner's manual before buying.
